Rotary base 370 mm for precision vises FPZ - POZ200P DARMET
Regular price:
Regular price:
product unavailable
add to wish list
0
Description
Technical information:
- POZ swivel base for precision vices FPZB, FPZD, FPZV in size 200.
- Made of high-performance alloy steel.
- 2 clamping legs fastened with screws.
- Rotation range: 120° with pin clamping / 360° without pin.
- Clear angle scale in 1° increments.
- Working surface hardness 58 - 62 HRC.
Specification:
| Parameter | Value |
|---|---|
| D | 26.5 / 17 mm |
| J | 250 mm |
| F | 26.5 / 17 mm |
| A | 175 mm |
| L | 170 mm |
| K | 13 mm |
| S | 34 mm |
| B | 370 mm |
| M | - |
| G | 71 mm |
| Groove | 16 mm |
| For vice model | FPZB200/300, FPZB200/400, FPZD200, FPZV200 |
| Weight | 21 kg |
Equipment:
| Base | 1 pc. |
| Mounting claws | 2 pcs. |
